Technical Performance:
|
Model |
motor size (mm) |
Rated Vol. |
Rated RPM. |
No Load Current |
Starting Voltage |
Operating Voltage |
|
|
Diameter |
overlength |
V DC |
RPM |
mA |
V DC |
V DC |
|
|
IND-GM-609-699-01 |
6.0 |
20.5 |
3.0 |
47±18%
|
60.0 Max |
1.5 Max |
2.2-3.6 |
Product Drawing:
Technical data:
Type D shaft, Ø 1.5*2.5mm, 6mm diameter, with 20mm wire length.
If you want a customized lead wire connection of the geared motors. Such as lead wire length & strip
lengths, with a connector (e.g. Molex, JST). Kindly contact us freely, any problems will be taken seriously
and will be answered professionally.
Product Advantages:
High efficiency, low noise, good sensitivity, long life, energy saving, fast response, etc.
Customized electric performance could be achieved on request.
You also could find the right haptic solution with our below various vibrators:
7-10mm diameter coin type brushed vibration motors.
3-4mm height reflow solderable SMD type vibration motors
4-7mm diameter cylinder type brushed vibration motors.
5-9 diameter coin type brushless vibration motors.These BLDC Motors have much longer lifetime than the normal brush type motors. At the test mode of 0.5s On 0.5s Off as one cycle, total lifetime can be 1 million cycles.
8-9 diameter coin type linear vibration motors. Vibrating in direction Z, vibration force at its peak acceleration value around 1.8G, much stronger than other normal brush type coin motors at 0.6-0.8G usually.
5) Main Application
Manufacturing all kinds of micro motor for over ten years. These motors are widely used in telecommunication devices and health-care products, medical devices and robotic products. Monthly capacity over 15 million motors.We have been making the best efforts to become one of the leading micro motor manufacturers in this industry. By investing ten percent of our annual revenue into R&D as well as advanced facilities, we continue to grow stably.Our mission is to produce cost effective products with good quality to satisfy our customers worldwide. This is the target we aim at now and forever......
1) Competitive Advantages
2) Production workshop (Part)
Worshop site 1 Worshop site 2
3) Production&Equipment
4) Packing & Shipping
Packing Details
100pcs per tray, 12 trays per carton, 1200 pcs per carton
Carton size: 34cm*34cm*21cm
Gross weight: 5.5kgs/ carton
Inner box bubble, then carton. And then reinforced with plastic pallet for outer packing. Or according to client's requirement.
Shipping Details
Samples Can be shipped within 10 days.
Mass production order leading time according to the actual situation.
